High bandwidth tolerance, for 5.5G/6G/LEO application.

Antennas play a crucial role in advancing technology, propelling industries towards a future of seamless connectivity. At Swiftlink, we pave the way for next-gen communication solutions.

Antenna Array:

The Antenna Array is a multi-polarization phased array antenna system, expertly designed to cover the full band of millimeter-wave (mmWave) frequencies. Leveraging flip-chip packaging technology, it boasts an ultra-compact size without compromising its broad frequency coverage and high performance. Its scalable design means it can easily be extended to support Multiple-Input, Multiple-Output (MIMO) systems or hybrid phased arrays. This level of adaptability makes it ideal for meeting diverse network requirements. By optimizing both space and functionality, the Antenna Array paves the way for next-generation wireless communication systems, offering enhanced capacity, coverage, and data rates.

SLK1201: Full-band, Dual-polarized 2×2 Array



4-element linear array with dual-polarization operation.

Operating bandwidth: 24 – 44 GHz.

Supported bands: n257, n258, n259, n260, n261.

Maximum realized gain: 13.9 dBi

Stable radiation patterns over the full band

Wide-angle scanning performance



SLK2301: Full-band, Single-polarized 2×4 Array



4-element linear array with dual-polarization operation.

Operating bandwidth: 24 – 44 GHz.

Supported bands: n257, n258, n259, n260, n261.

Maximum realized gain: 13.9 dBi

Stable radiation patterns over the full band

Wide-angle scanning performance



SLK320x (SLK3201 & SLK3202): Dual-band, dual-polarization 2×2 Array



4-element 2×2 array with dual-band, dual-polarization operation.

Operating bandwidth: 26.5 – 29.5 GHz and 37 – 40 GHz.

Supported bands: n257, n260.

Low band maximum realized gain: 1~1.5 dBi.

High band maximum realized gain: ~13.0 dBi.

Frequency stable radiation patterns in both bands.

Below -15 dB inter-element coupling.



SLK3204: Dual-band, dual-polarization 4-element Linear Array



4-element linear array with dual-band, dual-polarization operation.

Operating bandwidth: 26.5 – 29.5 GHz and 37 – 40 GHz.

Supported bands: n257, n260.

Low band maximum realized gain > 10 dBi.

High band maximum realized gain > 12 dBi.

Frequency stable radiation patterns in both bands

Below -12 dB inter-element coupling.
